Agilent Technologies Agilent 3499A User Manual

319
Chapter 9 Specifications
N2268A 50Ω 3.5GHz Dual 1-to-4 MUX Module
4
9
N2268A 50
Ω
3.5GHz Dual 1-to-4 MUX Module
INPUT CHARACTERISTICS
Total Channels: Dual 1-to-4 Chans
Maximum Switching Voltage:
Any center/shield to any other
center/shield/chassis:
30 V, dc or peak AC
Maximum Switching Current:
Per Channel:
Per Module:
0.5 A, dc or peak AC
1 A, dc or peak AC
Maximum Switching Power:
Per Channel:
Per Module:
10 W
20 W
Characteristic Impedance:
50 Ω
Relay Life:
Mechanical:
10mA/24VDC resist. load:
10W 2.5G 50Ω:
5 x 10
6
3x10
5
10
5
Thermal Offset:
Per Channel: 3 µV
Initial Closed Channel
Resistance:
<1 Ω
Maximum Scan Rate:
20 Chans/sec
DC CHARACTERISTICS
Open Channel,
Channel-Channel:
(with 1 Channel closed)
< (40
o
C, 50% RH):
< (40
o
C, 80% RH):
> 10
10
Ω
> 10
9
Ω
HI-LO:
(with 1 Channel closed)
< (40
o
C, 50% RH):
< (40
o
C, 80% RH):
> 10
10
Ω
> 10
9
Ω
Channel-Chassis:
(with 1 Channel closed)
< (40
o
C, 50% RH):
< (40
o
C, 80% RH):
> 10
10
Ω
> 10
9
Ω
