Agilent Technologies Agilent 3499A User Manual

323
Chapter 9 Specifications
N2272A 1 GHz RF 1-to-9 MUX Module
4
9
N2272A 1 GHz RF 1-to-9 MUX Module
INPUT CHARACTERISTICS
Total Channels:
1-to-9
Relay Type:
Latching
Connector Type:
BNC
Maximum Switching Voltage:
24 VDC
Maximum Switching Current:
1 A
Maximum Switching Power:
24 W
Characteristic Impedance:
50Ω
Relay Life:
Mechanical:
Electrical@1A24VDC:
5X10
6
10
5
DC CHARACTERISTICS
Offset Voltage (mV):
8.0
Initial Closed Channel
Resistance (
Ω
):
0.8
Insulation Resistance (
Ω
):
@(25
o
C, 40%RH)
(Open Ch, Ch-Ch):
(Ch-Chassis, Ch-Center):
@(40
o
C, 80%RH)
(Open Ch, Ch-Ch):
(Ch-Chassis, Ch-Center):
1010
10
10
10
9
10
9
