22
Chapter 1 Quick Start
Basic Operation
1
To Open All Channels on a Module
You can open individual channels on a module one at a time as described
above. There are times, however, when it would be more expedient to
open all channels on a module at once.
Use the arrow keys to select the module to work with. You cannot have
an individual channel selected for this operation. For example, select the
module in slot 1 (using the N2260A as an example) to show a display
similar to this:
Press and hold the card reset key. When you first press the key, the
display shows:
When the card has been reset, the display briefly shows:
and then returns to:
To Reset All Modules
You can reset all channels on all modules in the mainframe at once.
Press the shift key and then press and hold the reset key. The display
shows:
When the mainframe has been reset, the display will briefly show the
reset and then return to the slot or channel display.
N2260A
1
HOLD TO RESET
RESET CARD
N2260A
1
HOLD TO RESET
RESET . . .
