Agilent Technologies Agilent 3499A User Manual

306
Chapter 9 Specifications
N2261A 40-Channel GP Relay Module
9
AC ISOLATION / PERFORMANCE
a
(without terminal block)
Capacitance:
(with 1 channel closed)
Open Channel, Channel-
Channel:
Channel-Chassis:
< 10 pF
< 20 pF
Insertion Loss:
(with 50
Ω
termination)
100 kHz:
1 MHz:
10 MHz:
< 0.10 dB
< 0.20 dB
< 0.50 dB
Crosstalk:
(with 50
Ω
termination)
100 kHz:
1 MHz:
10 MHz:
< -70 dB
< -50 dB
< -30 dB
a. With chassis of all instruments connected, and with Low Terminal of the input connected to Low Terminal of the
output (either directly or via the 3499A/B/C switching channels).
