311
Chapter 9 Specifications
N2264A Multifunction Module
4
9
12-Channel GP Relay Function
INPUT CHARACTERISTICS
Total Channels:
12
Maximum Voltage:
Terminal-Terminal or
Terminal-Chassis:
200 V, dc or ac rms
Maximum Current:
Per Channel: 1 A, dc or ac rms
Maximum Power:
Per Channel: 60 W dc; 62.5 VA ac
Thermal Offset:
Per Channel: < 3 µV
Initial Closed Channel
Resistance:
< 0.5
Relay Life:
Mechanical:
Electrical:
10
8
(at 36000 operations/hour)
5 x 10
5
(1A load)
Maximum Scan Rate: 80 Chans/sec
DC ISOLATION (with terminal block)
Open Channel,
Channel-Channel:
(with 1 channel closed)
< (40
o
C, 50% RH):
< (40
o
C, 80% RH):
> 10
10
> 10
9
Channel-Chassis:
(with 1 channel closed)
< (40
o
C, 50% RH):
< (40
o
C, 80% RH):
> 10
10
> 10
9
AC ISOLATION / PERFORMANCE
a
(without terminal block)
Capacitance:
(with 1 channel closed)
Open Channel, Channel-Channel:
Channel-Chassis:
< 10 pF
< 20 pF
Insertion Loss:
(with 50
termination)
100 kHz:
1 MHz:
10 MHz:
< 0.10 dB
< 0.20 dB
< 0.50 dB
Crosstalk:
(with 50
termination)
100 kHz:
1 MHz:
10 MHz:
< -70 dB
< -50 dB
< -30 dB
a. With chassis of all instruments connected, and with Lo Terminal of the input connected to Lo Terminal of the
output (either directly or via the 3499A/B/C switching channels).
