Chapter 2 Front-Panel Operation
To Use a Digital I/O Port
4
2
5. Turn the knob until the desired data display format (i.e., BINARY) is
displayed.
6. Press Enter to make the change and return to the first level of the
Mode menu.
7. Press Mode again to exit the current configuration, the CONFIG
annunciator turns off.
Note Once you have selected the data display format for a port, it applies to
both input and output operations on that port.
BINARY 090
DISP FORMAT
