47
Chapter 2 Front-Panel Operation
To Configure the Remote Interface
4
2
4. Press Enter to select the interface and show the first parameter.
5. Turn the knob to set GPIB address (i.e., 07). Valid addresses range
from 00 to 30.
6. Press Enter to show the second parameter.
7. Press Enter to enable the instrument to assert the SRQ line when
powered up. If the computer is so configured, this can be used to
interrupt the system computer.
To disable this feature, turn the knob to select “SRQ OFF” and press
Enter. The instrument returns to the first level of the menu.
8. Press Menu again to exit the menu.The CONFIG annunciator turns
off.
ADDRESS 09
ADDRESS 07
SRQ ON
To Next Page
