68
Chapter 3 System Overview
Plug-in Modules Overview
3
Multifunction Modules
A multifunction module combines two or more functions such as MUX,
GP, Matrix, Digital I/O or DAC onto a single module, making it possible
to implement a complicated switching application with fewer modules.
Therefore, the cost is reduced by minimizing the number of mainframes
and modules required.
Each separate function on a multifunction module can be operated
independently. For example, an Agilent N2265A can be used as both a
4 x 4 matrix module and a 16-bit digital I/O module.
The table below lists the available multifunction modules.
Model
Number
Module Name
Mainframe
Slots
Required
Relay
Type
Description
N2264A 12-Channel GP +
3-Channel High-
current GP +
16-Bit Digital I/O
Module
1 Non-
latching
The module provides 12-channel
SPST (Single-pole Single-throw)
GP relays for signals up to 200 V, 1
A, 3-channel high-current GP
relays for signals up to 125 V, 5 A,
and 16-bit digital I/O for sensing
and control of external devices up
to 42 V, 600 mA.
N2265A 4 x 4 Matrix +
16-Bit Digital I/O
Module
1 Latching The module provides 4 x 4 2-wire
matrix for signals up to 200V, 1A,
and 16-bit digital I/O for sensing
and control of external devices up
to 42 V, 600 mA.
