Power Meter Operation 2
E4418B Power Meter User’s Guide 91
Presetting the Power Meter
This section details the power meter’s preset conditions.
The GPIB address and command set, the data stored in the sensor
calibration tables and the zeroing and calibration data are not affected by
a preset. The calibration table selected is not affected.
Preset Conditions
The number of windows displayed is two.
Measurement units used is set to dBm.
• is set to 50 MHz.
• is set to 100%.
• is set to digital in the upper window and analog in the
lower window.
• is set to 20.000 dBm ( ) and –70.000 dBm ( ).
• is set to “3”.
• is set to “Off”
• is set to 90.000 dBm ( ) and –90.000 dBm ( ).
• is set to “Off”.
• is set to “OVER”.
• is set to “Low”
Freq
Cal Fac
Display Format
Anlg Mtr Scaling
Max
Min
Resolution 1 2 3 4
Limits Off/On
Limits
Max
Min
TTL Output Off/On
Limits OVER, UNDER, EITHER
Fail O/P High/Low
