2 Power Meter Operation
62 E4418B Power Meter User’s Guide
Setting the Resolution
The resolution of each of the power meter’s windows can be set to four
different levels (1, 2, 3, or 4).
These four levels represent:
• 1, 0.1, 0.01, 0.001 dB respectively if the measurement suffix is dBm or
dB.
• 1, 2, 3, or 4 significant digits respectively if the measurement suffix is
W or %.
The default value is 0.01 dB (3 digits).
To set the resolution on the currently selected window:
1 Press . The current setting of the resolution is highlighted on the
softkey.
2 To change this setting, press until the required
resolution setting is highlighted.
