Power Meter Operation 2
E4418B Power Meter User’s Guide 83
ON - Sets the RTS signal line permanently high.
IBFull - Sets the RTS signal line high while the receiver buffer can accept
more data and sets RTS low when the data buffer is full. The transmitter is
inhibited when CTS is low.
12 Press and use any of the arrow keys to select one of the following
from the pop- up menu:
OFF - Sets the DTR signal line permanently low.
ON - Sets the DTR signal line permanently high.
IBFull - Sets the DTR signal line high while the receiver buffer can accept
more data and sets DTR low when the data buffer is full. The transmitter is
inhibited when DSR is low.
The softkey is greyed out if the RS422 interface is selected.
Remote Interface Overview
You can view a summary of your remote interface settings at any time by
pressing
, , . Examples of an
GPIB and RS422 interface overview are shown in Figure 2- 19.
