5 Specifications
166 E4418B Power Meter User’s Guide
For Agilent E-Series power sensors
In FAST mode, within the range –50 dBm to +17 dBm, for a 10 dB decreasing
power step, the settling time is 10
ms
1
.
1
When a decreasing power step crosses the power sensor’s auto-range switch point, add 25 ms. Refer to the
relevant power sensor manual for further information.
For Agilent E- Series power sensors in normal and x2 speed modes, manual
filter, 10
dB decreasing power step:
Tab l e 5 - 5 Settling Time
Number of Averages 1 2 4 8 16 32 64 128 256 512 1024
Settling Time (s)
(Normal Mode)
0.07 0.12 0.21 0.4 1 1.8 3.3 6.5 13 27 57
Response Time (s)
(x2 mode)
0.04 0.07 0.12 0.21 0.4 1 1.8 3.4 6.8 14.2 32
To Next Page
