Menu Reference 3
E4418B Power Meter User’s Guide 111
The Front Panel Menu Maps
The following diagrams detail the structure of the softkey menus which are
accessed through the following seven keys:
•
•
•
•
•
•
•
dBm/W Menu
On your power meter, some softkey labels have numeric values displayed under them.
These values show the current setting of that softkey. Since these values are variable,
they are shown in a grayed out text on the following menu maps.
Depending on the power meter’s setup, you will be unable to select certain softkeys. The
text on these softkey labels appears grayed out. Refer to the appropriate softkey
descriptions for further information.
To Next Page
