Menu Reference 3
E4418B Power Meter User’s Guide 143
Press this key to:
• increment the alphanumeric digit on which the cursor is currently
positioned. That is, digits scroll 0 through 9 and characters lowercase a
through z, uppercase A through Z, then underscore.
• select fields for editing on the “Edit Table” screen.
• select a table in the “Sensor Cal Tables” screen.
• select a file in the “Save” and “Recall” screens.
Press this key to select the upper or lower measurement window on the power
meter’s display. The window which is selected is highlighted by a shadowed
box. Any measurement setup you create using
, and is
implemented in the selected window.
Press this key to choose from a one or a two window display.
Press this key to switch the power meter between on and standby. When the
power meter is switched to standby (that is, when this key is off but the power
is connected to the instrument) the red LED is lit. When the power meter is
switched on, the green LED is lit.
