2 Power Meter Operation
40 E4418B Power Meter User’s Guide
• Use or to move to other digits.
8 To confirm your choice, press the appropriate frequency units.
9 Connect the power sensor to the signal to be measured.
10 The measurement result is now displayed.
Example
To make a measurement using an Agilent E- Series power sensor. The
frequency of the signal to be measured is 100
MHz.
• Disconnect the power sensor from any source.
• Press .
• Press .
• Connect the power sensor to the POWER REF output.
• Press .
• Press , . Use the , , , and keys to
enter 100. Press .
• Connect the power sensor to the signal to be measured.
• The measurement result is now displayed.
