144 Chapter 5
Replaceable Parts
Replaceable Parts List
Rear View
Figure 5-10 Rear View
Table 5-9 Rear View
Ref.
Desig.
Agilent Part Number Qty. Description
1 0515-0372 2 SCREW-MACH M3.0 x L8 PN T10
2 0515-0372 2 SCREW-MACH M3.0 x L8 PN T10
3 0515-0372 2 SCREW-MACH M3.0 x L8 PN T10
4 2950-0035 2 NUT-HEX-DBL-CHAM
2190-0102 2 WSHR-LK INTL T
5 0515-0372 4 SCREW-MACH M3.0 x L8 PN T10
