Agilent Technologies ENA Series

18 Chapter 1
General Information
Required Equipment
Required Equipment
Table 1-1 lists the recommended equipment for performing maintenance on the
E5061A/E5062A.
Table 1-1 Recommended Test Equipment
Equipment Critical specifications Recommended Model Qty.
Use
*1
Frequency Counter Frequency: 50 MHz to 3 GHz
Accuracy: < 2.5 ppm
Agilent 53131A with
Opt.010 & 030
*2
1P,A
Power Meter No Substitute Agilent E4419B with Opt.
G12 or H12
*3
1P,A
Power Sensor No Substitute Agilent 8482A 1 P,A
Power Sensor (75 ) No Substitute Agilent 8483A with Opt.
H03
1P
Dynamic Accuracy
Test Kit
No substitute Agilent Z5623A with Opt.
H01
1P
Calibration Kit No Substitute Agilent 85032B 1 P,T
Calibration Kit No Substitute Agilent 85032F 1 A
Calibration Kit (75
)
No Substitute Agilent 85036B 1 P,A,T
Short Type-N(m), N(f) part of Agilent 85032B
with Type-N adapter
2P,T
Short (75 ) Type-N(m), N(f) part of Agilent 85036B
with Type-N adapter
2P,T
Fixed attenuator (6
dB)
50 , N(m)-N(f), VSWR  1.015 Agilent 8491A w/Opt.006
and H60
1P,A
Minimum Loss Pad 50  N(f)-75  N(m) Agilent 11852B 1 P,A
Minimum Loss Pad 50  N(m)-75  N(f) Agilent 11852B Opt. 004 1 P
Power Splitter N(m) 50  in, N(f) 50  out Agilent p/n 0955-0751 1 A,T
Power splitter (75 ) N(m) 75  in, N(f) 75  out Agilent p/n 0955-0752 1 A,T
Handler I/O Test Kit No substitute Agilent p/n E5070-65001 1 T
