76 Chapter 2
Performance Tests
E5062A Performance Test Record (for Option 175/275)
For Serial Prefix : MY442 and above
Direction: S21
Direction: S12 (Option 275 only)
Dynamic Accuracy Test
@ Reference power level: -10 dBm
100 M - 1.5 G 10  -115
1.5 G - 3 G 10  -115
300 k - 100 M 3 k  -90
100 M - 1.5 G 3 k  -90
1.5 G - 3 G 3 k  -90
Frequency range [Hz] IF bandwidth [Hz] Test limit [dB] Test result [dB]
Frequency range [Hz] IF bandwidth [Hz] Test limit [dB] Test result [dB]
300 k - 1 M 10  -115
1 M - 100 M 10  -120
100 M - 1.5 G 10  -120
1.5 G - 3 G 10  -120
300 k - 1 M 3 k  -90
1 M - 100 M 3 k  -95
100 M - 1.5 G 3 k  -95
1.5 G - 3 G 3 k  -95
Frequency range [Hz] IF bandwidth [Hz] Test limit [dB] Test result [dB]
300 k - 1 M 10  -115
1 M - 100 M 10  -120
100 M - 1.5 G 10  -120
1.5 G - 3 G 10  -120
300 k - 1 M 3 k  -90
1 M - 100 M 3 k  -95
100 M - 1.5 G 3 k  -95
1.5 G - 3 G 3 k  -95
