148 Chapter 5
Replaceable Parts
Replaceable Parts List
A21 PCI DSP CARD / A24 GPIB CARD Assembly
Figure 5-14 A21 PCI DSP CARD / A24 GPIB CARD Assembly
Table 5-13 A21 PCI DSP CARD / A24 GPIB CARD Assembly
Ref.
Desig.
Agilent Part Number Qty. Description
1 E5062-66521 1 PCI DSP CARD
2 E5062-01204 1 ANGLE PCI W/GPIB
3 2950-0054 1 NUT-HEX-DBL-CHAM
2190-0054 1 WSHR-LK INTL T
4 0515-0430 1 SCREW-MACH M3.0 x L6 PAN T10
5 E5062-65000 1 PCI GPIB CARD
6 0515-0430 2 SCREW-MACH M3.0 x L6 PAN T10
