154 Chapter 5

Replaceable Parts

Replaceable Parts List

Front Assembly (LCD) for E5061A : JP1KLxxxxx, MY44101900 and

below, E5062A : JP1KLxxxxx, MY44102842 and below

Figure 5-20 Front Assembly (LCD)

Table 5-19 Front Assembly (LCD)

Ref.

Desig.

Agilent Part Number Qty. Description

1 0515-1402 4 SCREW-MACH M3.5 x L8 PN T15

2 E5070-66531 1 LCD ADAPTER
