Agilent Technologies ENA Series

78 Chapter 2
Performance Tests
E5062A Performance Test Record (for Option 175/275)
Uncorrected System Performance Test
@ Correction: Off
S21 or S11
-15  0.065  0.011
-20  0.073  0.011
-25  0.080  0.015
-30  0.087  0.015
-35  0.095  0.019
-40  0.103  0.019
-45  0.111  0.022
-50  0.121  0.022
-55  0.134  0.024
-60  0.150  0.024
-65  0.174  0.026
-70  0.211  0.026
-75  0.270  0.028
-80  0.371  0.028
-85  0.546  0.030
-90  0.841  0.030
-95  1.334  0.032
-100 2.141  0.032
Power level [dBm] Test limit [dB] Test result [dB] Measurement
uncertainty [dB]
System
performance
Frequency range [Hz] Test limit [dB] Test result [dB]
Directivity 300 k - 100 M  -25
Directivity 100 M - 1.5 G  -25
Directivity 1.5 G - 3 G  -25
Source match 300 k - 100 M  -25
Source match 100 M - 1.5 G  -25
Source match 1.5 G - 3 G  -25
