Agilent Technologies ENA Series

Chapter 2 75
Performance Tests
E5062A Performance Test Record (for Option 175/275)
2. Performance Test
Crosstalk Test
Direction: S21
Direction: S12 (Option 275 only)
System Dynamic Range Test
For Serial Prefix : JP1KL or MY441
Direction: S21
Direction: S12 (Option 275 only)
100 M - 1.5 G 3 k  0.03
1.5 G - 3 G 3 k  0.03
Frequency range
[Hz]
IF bandwidth
[Hz]
Test limit [deg
rms]
Test result [deg
rms]
Frequency range [Hz] IF bandwidth [Hz] Test limit [dB] Test result [dB]
300 k - 100 M 10  -110
100 M - 1.5 G 10  -110
1.5 G - 3 G 10  -110
Frequency range [Hz] IF bandwidth [Hz] Test limit [dB] Test result [dB]
300 k - 100 M 10  -110
100 M - 1.5 G 10  -110
1.5 G - 3 G 10  -110
Frequency range [Hz] IF bandwidth [Hz] Test limit [dB] Test result [dB]
300 k - 100 M 10  -115
100 M - 1.5 G 10  -115
1.5 G - 3 G 10  -115
300 k - 100 M 3 k  -90
100 M - 1.5 G 3 k  -90
1.5 G - 3 G 3 k  -90
Frequency range [Hz] IF bandwidth [Hz] Test limit [dB] Test result [dB]
300 k - 100 M 10  -115
