Chapter 5 153

Replaceable Parts

Replaceable Parts List

5. Replaceable Parts

Front Assembly (Inverter)

Figure 5-19 Front Assembly (Inverter)

Table 5-18 Front Assembly (Inverter)

Ref.

Desig.

Agilent Part Number Qty. Description

1 0515-1974 2 SCREW-MACH M2.5 x L4 PN T8

2 0950-4091 1 INVERTER

3 E5070-01211 1 BRACKET INVERTER

4 E5070-61627 1 WIRE ASSY
