Chapter 5 149

Replaceable Parts

Replaceable Parts List

5. Replaceable Parts

Analog Mother Board Assembly

Figure 5-15 Analog Mother Board Assembly

Table 5-14 Analog Mother Board Assembly

Ref.

Desig.

Agilent Part Number Qty. Description

1 E5062-66510 1 ANALOG MOTHER BOARD

2 0515-0372 4 SCREW-MACH M3.0 x L8 PN T10
