Agilent Technologies ENA Series

62 Chapter 2
Performance Tests
E5062A Performance Test Record (for Option 150/250)
Direction: S21 (Phase)
Direction: S12 (Magnitude) (Option 250 only)
Direction: S12 (Phase) (Option 250 only)
Direction: S11 (Magnitude) (Option 150 only)
Frequency range
[Hz]
IF bandwidth
[Hz]
Test limit [deg
rms]
Test result [deg
rms]
300 k - 1 M 3 k  0.05
1 M - 100 M 3 k  0.03
100 M - 1.5 G 3 k  0.03
1.5 G - 3 G 3 k  0.03
Frequency range
[Hz]
IF bandwidth
[Hz]
Test limit [dB rms] Test result [dB rms]
300 k - 1 M 3 k  0.008
1 M - 100 M 3 k  0.005
100 M - 1.5 G 3 k  0.005
1.5 G - 3 G 3 k  0.005
Frequency range
[Hz]
IF bandwidth
[Hz]
Test limit [deg
rms]
Test result [deg
rms]
300 k - 1 M 3 k  0.05
1 M - 100 M 3 k  0.03
100 M - 1.5 G 3 k  0.03
1.5 G - 3 G 3 k  0.03
Frequency range
[Hz]
IF bandwidth
[Hz]
Test limit [dB rms] Test result [dB rms]
300 k - 1 M 3 k  0.008
1 M - 100 M 3 k  0.005
100 M - 1.5 G 3 k  0.005
1.5 G - 3 G 3 k  0.005
