Agilent 1100 Series Fraction Collectors User’s Guide 47
Troubleshooting and Test Functions 2
Status Indicators
Status Indicators
Two status indicators are located on the front of the fraction collector. The
lower left indicates the power supply status, the upper right indicates the
fraction collector status.
Power Supply Indicator
The power supply indicator is integrated into the main power switch. When
the indicator is illuminated (green) the power is ON.
Figure 20 Location of Status Indicators
Status
indicator
green/yellow/
red
Line power
switch with
green light
