Agilent 1100 Series Fraction Collectors User’s Guide 57
Repairing the Fraction Collector 3
Overview of Main Repair Procedures
Overview of Main Repair Procedures
Figure 23 Main Assemblies (Example displays the analytical scale module G1364C. The
preparative scale fraction collector G1364B contains a different needle)
Internal tray with
rinse port and
flow delay sensor
Diverter Valve
Tra ns po rt un it
Plug channel with air
channel adapter
underneath
BCD Board (optional)
Main board
Needle
SLF-board
Power supply
Needle carrier
Leak plane with
leak sensor
Tray compartment
divider
Ribbon cable
Inlet / waste tubings
Wellplate Adapter
