Reviewing Incident Data
7-4 Data Management and Review
This information stays in the HEARTSTREAM FR2’s memory and can be
displayed for review until the next time the H
EARTSTREAM FR2 is used. At
that time, the data from the new incident will be displayed.
Reviewing Data from a Data Card
If a data card is installed when the HEARTSTREAM FR2 is turned on for use
during an incident, the H
EARTSTREAM FR2 automatically records detailed
information on the data card. To review this information on the
H
EARTSTREAM FR2 screen:
1. Make sure the Training & Administration Pack is not installed.
2. Make sure the data card is installed. Unplug the pads connector.
3. Remove and reinstall the battery.
4. Select REVIEW INCIDENT from the menu. A new screen comes up.
This screen displays:
ELAPSED TIME — how long the incident recorded by the FR2
lasted,
SHOCKS DELIVERED — how many shocks were delivered during
the incident, and
FIRST SHOCKS AT — the time the first three shocks were delivered.
NOTE: If the data card does not contain both an events file and presenting ECG data,
only the summary information from FR2 internal memory will be displayed when
REVIEW INCIDENT is selected.
5. To review the events that occurred during the incident, select REVIEW
EVENTS. A new screen comes up. This and following screens, accessed
by selecting NEXT EVENTS, display elapsed time information for
critical activities in using the H
EARTSTREAM FR2. These include:
POWER ON — when the HEARTSTREAM FR2 was turned on,
PADS ON — when the defibrillation pads were connected and
removed,
SHOCK ADVISED — when a shock was advised or not advised,
ARMED — when the FR2 charged for shock delivery,
SHOCKED — when a shock was delivered,
REVIEW INCIDENT
RETURN
REVIEW EVENTS
REVIEW ECG
ELAPSED TIME: 3:18
SHOCKS DELIVERED 6
FIRST SHOCKS AT:
00:18 01:10 01:49
REVIEW EVENTS
RETURN
NEXT EVENTS
POWER ON 0:00
PADS ON 0:04
SHOCK ADVISED 0:13
ARMED 0:18
SHOCKED 0:22
