HEARTSTREAM FR2 AED Specifications
M3860A and M3861A H
EARTSTREAM FR2 Defibrillator B-5
B
Display
Non-Shockable Rhythm —
All other non-shockable
rhythms
450 Meets AAMI DF39 requirement and AHA recommendation
†
(specificity >95%)
*. From Agilent Technologies Heartstream Operation ECG rhythm databases.
†. Automatic External Defibrillators for Public Access Use: Recommendations for Specifying and Report-
ing Arrhythmia Analysis Algorithm Performance, Incorporation of New Waveforms, and Enhancing
Safety. American Heart Association (AHA) AED Task Force, Subcommittee on Safety & Efficacy, draft
3/18/96, Table 2.
RHYTHM CLASS
ECG TEST
SAMPLE
*
SIZE
NOMINAL SPECIFICATIONS
CATEGORY NOMINAL SPECIFICATIONS
Monitored ECG Lead ECG information is received from defibrillation pads in anterior-anterior (Lead II)
position. (Displayed on M3860A only.)
Display Range (M3860A only) Differential: +/-2 mV full scale, nominal.
Screen Type High-resolution liquid crystal display (LCD) with backlight.
Screen Dimensions 2.8" wide x 2.3" high (70 mm x 58 mm).
Sweep Speed (M3860A only) 23 mm/s nominal.
ECG Display 3 second-segments displayed (M3860A only)
Frequency Response
(Bandwidth)
Nondiagnostic rhythm monitor 1 Hz to 20 Hz (-3 dB), nominal.
Sensitivity 1.16 cm/mV, nominal.
Heart Rate Displayed
(Normal Sinus Rhythm)
30 to 300 bpm, updated each analysis period. Displayed (M3860A only) during
monitoring and advanced modes.
