HEARTSTREAM FR2 AED Specifications
M3860A and M3861A H
EARTSTREAM FR2 Defibrillator B-3
B
Charge Time from “Shock
Advised”
< 10 s typical, including confirming analysis. Charge time increases near end of
battery service life.
Shock-to-Shock Cycle Time < 20 s typical, including analysis, in AED mode.
“Charge Complete”
Indicator
Shock button flashes, audio tone sounds.
Disarm (AED mode) Once charged, the HEARTSTREAM FR2 will dump the charge if:
• if patient’s heart rhythm changes to non-shockable rhythm, OR
• a shock is not delivered within 30 s after the FR2 is armed, OR
• the PAUSE button (if enabled) is pressed, OR
• the On/Off button is pressed to turn off the FR2, OR
• the defibrillation pads are removed from the patient or the pads connector is
disconnected from the FR2.
Disarm (advanced mode) Once charged, the HEARTSTREAM FR2 will dump the charge if:
in advanced mode ANALYZE
• the MANUAL DISARM button is pressed, OR
• if patient’s heart rhythm changes to non-shockable rhythm, OR
• a shock is not delivered within 30 s after the FR2 is armed, OR
• the On/Off button is pressed to turn off the FR2, OR
• the defibrillation pads are removed from the patient or the pads connector is
disconnected from the FR2.
in advanced mode CHARGE (M3860A only)
• the MANUAL DISARM button is pressed, OR
• a shock is not delivered within 30 s after charging , OR
• the On/Off button is pressed to turn off the FR2, OR
• the defibrillation pads are removed from the patient or the pads connector is
disconnected from the FR2.
Shock Delivery Vector Via defibrillation pads placed in the anterior-anterior (Lead II) position.
CATEGORY NOMINAL SPECIFICATIONS
