7 General Maintenance
To Disassemble the EI XTR Source
202 5977B Series MSD Operating Manual
Figure 65. Disassembling the EI XTR source
Table 21 Parts list for EI XTR source (Figure 65)
Item Description Part number
1 Setscrews G3870-20446
2 Screws G3870-20021
3 Source body G3870-20440
4 Extractor lens G3870-20444
5 Extractor lens insulator G3870-20445
6 Filaments G7005-60061
7 Spring washer 3050-1301
7 Flat washer 3050-0982
