Service Guide N5230-90024 4-33
PNA Series Microwave Network Analyzers Troubleshooting
N5230C Measurement System Troubleshooting
12 10.5.00 to 12.500 11.500 1.917 3.833
13 12.500 to 15.750 14.000 2.334 4.667
14 15.750 to 16.667 16.100 2.684 5.367
15 16.667 to 18.750 17.700 2.950 5.900
16 18.750 to 21.000 19.800 1.650 6.600
17 21.000 to 22.500 21.700 1.808 7.233
18 22.500 to 25.000 23.700 1.975 7.900
19 25.000 to 26.250 25.600 2.133 8.533
20 26.250 to 26.500 26.400 2.200 8.800
21 26.500 to 28.600 27.500 2.292 9.167
22 28.600 to 31.250 30.000 3.000 6.000
23 31.250 to 31.500 31.400 1.570 6.280
24 31.500 to 33.333 32.400 1.620 6.480
25 33.333 to 37.000 35.400 1.770 7.080
26 37.000 to 40.500 38.800 1.940 7.760
27 40.500 to 41.667 41.000 2.050 8.200
28 41.667 to 42.000 41.800 2.090 8.360
29 42.000 to 46.800 44.400 2.220 8.880
30 46.800 to 50.000 48.400 2.420 9.680
Table 4-4 LO Path Frequencies
Band
Network Analyzer
Frequency Band of Problem
(GHz)
Network Analyzer Source
Frequency Setting (GHz)
Expected A7
Output Frequency
(GHz)
Expected A6
Output Frequency
(GHz)
