Performance Tests and Calibration 7
Agilent U1251A/U1252A User’s and Service Guide 131
Perform the verification test steps in the following Table 5:
Tab l e 5 Verification Test
Step Test Function Range 5520A Output
Error from nominal 1 year
U1251A U1252A
1 Turn the rotary switch to the
V position
[1]
5 V 5 V, 1 kHz ± 32.5 mV ± 22.5 mV
5 V, 10 kHz ± 52.5 mV ± 22.5 mV
5 V, 20 kHz N/A ± 41.5 mV
5 V, 30 kHz ± 84 mV N/A
4.5 V, 100 kHz N/A ± 169.5 mV
50 V 50 V,1 kHz ± 325 mV ± 225 mV
50 V,10 kHz ± 525 mV ± 225 mV
50 V, 20 kHz N/A ± 415 mV
50 V, 30 kHz ± 840 mV N/A
45 V, 100 kHz N/A ± 1.695 V
500 V 500 V, 1 kHz ± 3.25 V ± 2.25 V
500 V, 10 kHz ± 5.25 V ± 2.25V
1000 V 1000 V, 1 kHz ± 10 V ± 8.0 V
2 Press button to go to
frequency mode
9.9999kHz 0.48 V, 1 kHz ± 500 mHz ± 500 mHz
3 Press button to go to
Duty Cycle mode
0.01% – 99.99% 5.0 Vpp @
50%, Square
Wave, 50 Hz
± 0.315% ± 0.315%
