Valid Adjustment Input Values
Adjustment can be accomplished using the following input
values below.
Tab l e 6 Valid adjustment input values
Function Range Valid Amplitude Input Values
5V, 50 V, 500 V, 1000 V
0.9 to 1.1 x Full Scale
V
(for U1251A)
5 V, 50 V, 500 V, 1000 V
0.9 to 1.1 x Full Scale
(for U1252A)
5 V, 50 V ,500 V, 1000 V
0.9 to 1.1 x Full Scale
50 mV, 500 mV, 1000 mV
0.9 to 1.1 x Full Scale
500 µA, 5000 µA
0.9 to 1.1 x Full Scale
50 mA, 440 mA, 5 A, 10 A
0.9 to 1.1 x Full Scale
Ω
500 Ω, 5kΩ, 50 kΩ,500 kΩ, 5MΩ,
50 MΩ
0.9 to 1.1 x Full Scale
/ TEMP
10 nF, 100 nF, 1000 nF, 10
µF, 100 µF,
1000
µF, 10 mF / 0 °C
Make sure to provide 0 °C with
ambient compensation
