The primary display signs are described below.
LCD Sign Description
Auto range
AC + DC
DC
AC
Polarity, digits and decimal points for primary display
dBm Decibel unit relative to 1 mW
dBV Decibel unit relative to 1 V
MkHz Frequency units: Hz, kHz, MHz
MkΩ Resistance units: Ω, kΩ, MΩ
nS Conductance unit
mV Voltage units: mV, V
µmA Current units: µA, mA, A
% Duty cycle measurement
ms Pulse width unit
µmnF Capacitance units: nF, µF, mF
ºC Celsius temperature unit
ºF
Fahrenheit temperature unit
%
Percentage scale readout proportional to DC 0–20 mA
%
Percentage scale readout proportional to DC 4–20 mA
