The “+” or “–” sign is indicated when the positive or
negative value has been measured or calculated. Each
segment represents 2500 or 500 counts depending on the
range indicated on the peak bar graph. See the table below.
Range Counts / Segment Used for the Function
2500 V, A, Ω, Diode
2500 V, A, Ω
2500 V, A, Ω, nS
500
V, A,
500
500
