84 Agilent U1251A/U1252A User’s and Service Guide
4 Changing The Default Setting
Menu item
Available setting options Default factory
setting
Display
Description
Display Description
Print
Print
ON, OFF Enables auto send of data to the PC continuously
when set to ON
OFF
rESEt
Reset
dEFAU Enables the reset of factory settings by pressing
and holding for more than 1 second
dEFAU
tEMP
Te m p e r a t u r e
(4)
d-CF Sets the temperature measurement to °C but
pressing swaps the display to °F
d-CF
d-F Sets the temperature measurement to °F
d-FC Sets the temperature measurement to °F but
pressing
swaps display to °C
d-C Sets the temperature measurement to °C
1. This is the first display once the meter enters the Setup mode.
2. For d-LoG and rEF menu items, press to select the digit to be
adjusted.
3. J-type thermocouple applies to U1252A.
4. To view the tEMP menu item, press for more than 1 second.
