ahlmann AS 210 - Axle Loads; Tyres; Steering System; Brake System

S200/S201/Z200 11-3
Technical Data (Loader) 11
11.6 Axle loads
- Perm. axle loads - front 9.500 kg
- rear 9.500 kg
- Perm. total weight 16.500 kg
11.7 Tyres
The following tyres are permitted:
- Size 20.5 - 25
- Tyre pressure - front 3.0 bar
- rear 3.0 bar
- Size 20.5 R 25
- Tyre pressure - front 3.0 bar
- rear 3.0 bar
11.8 Steering system
- Four-wheel (can be switched to rear-wheel steering)
- Hydrostatic via priority valve
- Pressure max. 140 bar
11.9 Brake system
- Service brake:
Hydraulic wet lamella brake in the front and rear axles, acting on all four wheels.
- Parking brake:
Spring-loaded wet lamella brake in the rear axle.
- Flow rate pump III 36 l/min
11.10 Electrical system
- Battery 2 x 88 Ah
11.11 Hydraulic system
- Contents 230 l
- Hydraulic oil reservoir 180 l
11.11.1 Working hydraulics
- Flow rate pump I (via priority valve) 114 l/min
- Flow rate pump II (via swivel unit) 60 l/min
- Total flow rate 174 l/min
- Operating pressure max. 220 bar
- 2 lift cylinders Ø 110 mm
- 2 tip cylinders Ø 110 mm
- Times acc. to DIN ISO 7131
Lift (with payload) 6.0 s
Lower (without load) 3.5 s
Dump 90° 1.5 s
Tilt 45° 1.0 s
11.11.2 Swivel unit hydraulics
- Flow rate pump II (via shut-off valve) 60 l/min
- Operating pressure max. 180 bar
- 2 swivel cylinders Ø 110 mm
- Time to swivel 180° 15.0 s
