11 Technical Data (Loader)
11 Technical data (loader)
NOTE
The technical data refer to 20.5 -25 tyres.
11.1 Loader
- Height 3.155 mm
- Width 2.660 mm
- Wheelbase 2.400 mm
- Track width 2.080 mm
- Operating weight w/o attachment 13.800 kg
- Ground clearance
- Distribution gear 500 mm
- Differential 495 mm
- Turning radius (with four-wheel steering) - across the rear 4.985 mm
- across the bucket 6.080 mm
- wheels internal 2.265 mm
- Steering angle +/- 25°
- Swinging angle +/- 10°
- Climbing ability with payload
due to the permitted slanting of the engine, limited to 60 %
- Max. lifting capacity 106 kN
- Max. thrust force 113 kN
- Tear-out force 130 kN
11.2 Engine
- Type BF6M 2012C
- Water-cooled turbodiesel engine with charge air-cooling
- 6 cylinders, 4-stroke, direct injection
- Displacement 6.057 cm
3
- Performance acc. to ISO 9249 128 kW at 2.200 rpm
- Cooling system Water
- Total coolant approx. 16 l
- Anti-freeze 8 l
- Exhaust gas emission acc. to RL 97/68 EC level 2 + EPA
11.3 Starter
- 4 kW, 24 V
11.4 Alternator
- 55 A, 24 V
11.5 Hydrostatic drive motor
“20 km/h” variant
Alpha max 0........4.5 km/h
1st gear shift: 0........11 km/h
2nd gear shift: 0........20 km/h
“35 km/h” variant
Alpha max. 0........4.5 km/h
1st gear shift: 0........11 km/h
2nd gear shift: 0........35 km/h
