S220/S221/S230/S231/Z2008-4
8 Maintenance
Figure 8-1
Figure 8-3
Figure 8-2
8.2 Maintenance work
8.2.1 Engine oil level check
See the operating instructions for the engine.
8.2.2 Coolant level check
The coolant level of the engine is to be checked each time
that the loader is started or at least once per day. The
compensation tank (8-1/arrow) in the motor compartment
is located on the right side of the loader; the filling hole is
located at the engine hood (8-2/arrow). The level of coolant
must be between the „Minimum“ and „Maximum“ marks.
CAUTION
If coolant needs to be added, note that the water/
anti-freeze mixing ratio is 2:1!
8.2.3 Oil level check for axles
8.2.3.1 Rear axle
(1) Unscrew the plug from the axle arch (8-3/arrow).
NOTE
- The oil level must reach the plug bore.
- Collect any oil that escapes.
(2) Fit a new gasket and screw the plug back in.
