S200/S201/S210/S211/Z200
Diagrams 10
10-1
10.1 Electric wiring diagram
Item Designation
01 Indicator lamp assembly
02 Fuel gauge
03 Coolant temperature gauge
04 Tachometer
05 Operating hours meter
06 Actuator: release of quick-change device
07 Actuator: rear window wiper/washer
08 Actuator: road lights
09 Actuator: hazard flasher
10 Start switch
11 Indicator lamp assembly for gear shift
12 Steering column switch
