S200/S201/S210/S211/Z200
10 Diagrams
10-2
Item Designation
13 Fuse (chapter 4.9/A1) Hydraulics
14 Fuse (chapter 4.9/A2) Heater
15 Fuse (free) free
16 Fuse (chapter 4.9/A4) Engine shut-off
17 Fuse (chapter 4.9/A5) Fan
18 Fuse (chapter 4.9/A6) Brake lights
19 Fuse (chapter 4.9/A7) Rear window heater
20 Fuse (chapter 4.9/A8) Traction drive
21 Fuse (chapter 4.9/B1) Turn indicator
22 Fuse (chapter 4.9/B2) Windshield wiper/washer
23 Fuse (free) free
24 Fuse (free) free
25 Fuse (chapter 4.9/B5) Parking light, left
26 Fuse (chapter 4.9/B6) Parking light, right
27 Light indicator diode (chapter 4.9/B7) Diode light
28 Light indicator diode (chapter 4.9/B8) Diode light
29 Fuse (chapter 4.9/C1) Hazard flasher
30 Fuse (chapter 4.9/C2) Warning beacon (opt.), headlamp flasher
31 Fuse (chapter 4.9/C3) 2-pole socket
32 Fuse (chapter 4.9/C4) Cigarette lighter
33 Fuse (chapter 4.9/C5) Interior lighting
34 Fuse (chapter 4.9/C6) Working lights
35 Fuse (chapter 4.9/C7) Dipped beam
36 Fuse (chapter 4.9/C8) High beam
37 Relay for auxiliary hydraulics: close bucket
38 Relay for auxiliary hydraulics: open bucket
39 Relay for differential lock
40 Relay for parking brake
41 Relay for reversing buzzer / tail light / reversing beacon
42 Relay for drive motor (only for slow loaders)
43 Relay for working lights
44 Stabilized power source
45 Control for gear shift
46 Interval timer
47 Turn signal relay
48 Acoustic warning buzzer
