ahlmann AS 210 - Switching the Steering Type

S220/S221/S230/S231/Z200 5-11
Operation 5
(5) Adjusting the backrest:
Use the locking lever (5-15/arrow) to adjust the backrest.
NOTE
The locking lever must engage in the desired
position. It must be impossible to move the
backrest to another position when the lever has
engaged.
(6) Longitudinal adjustment:
You can adjust the seat in longitudinal direction when you
pull the lever (5-16) upwards.
NOTE
The locking lever must engage in the desired
position. It must be impossible to move the driver’s
seat to another position when the lever has
engaged.
5.5 Switching the steering type
CAUTION
- The wheels of the rear axle must be straight
before the switching lever (5-17/arrow) can
be applied.
- Enable the steering switch only when the
loader is at a standstill. To switch the steering
type, move the hand lever to the right (rear-
axle steering) or to the left (four-wheel
steering).
Figure 5-17
Figure 5-16
Figure 5-15
i
i
