S220/S221/S230/S231/Z2004-2
4 Description
123456 7 8 9
15 14 13 12 11 10
4 Description
Figures and descriptions may vary due to modifications in the construction that become possible and necessary
to improve the loader and to develop it further technically.
These modifications are summarised in section 13.
4.1 Overview
1 - Bucket protection
2 - Bucket/attachment
3 - Deflection lever
4 - Tip cylinder
5 - Bucket arm
6 - Lift cylinder
7 - Driver’s cab
8 - Drive motor
9 - Hydraulic oil reservoir / filler neck
10 - Rear axle
11 - Battery compartment
12 - Tool box
13 - Revolving seat
14 - Front axle
15 - Quick-change device
16 - Fuel tank, right loader side (not shown)
Figure 4-1
