S220/S221/S230/S231/Z2007-2
7 Rescue, Towing,
Lashing, Lifting by Crane
7 Rescue, towing, lashing, lifting
by crane
7.1 Rescue, towing, lashing
7.1.1 Rescue/towing of the swivel shovel
loader if the engine or drive has failed
DANGER
Secure the rescue location if it is on a public road.
CAUTION
- The swivel shovel loader must not be tow-
started. Any attempt to tow-start leads to
damage.
- Towing is permitted only to remove the loader
from a danger zone and to load it onto a low
loader.
NOTE
Preparation for towing depends on whether the
engine has failed, thus causing a failure of the
entire hydraulic system, or if only the drive has
failed and the engine can drive the rest of the
hydraulic system.
7.1.1.1 Towing the swivel shovel loader if the
engine has failed
(1) Actuate the toggle switch for the hazard flasher
(4-5/6).
(2) Secure both wheels of the front axle against rolling
away in both directions.
(3) Set the drive switch (4-9/5) to “0”.
NOTE
The preparations described in steps (4), (6), (7)
and (13) are only to be carried out if the rescue
location is not on a public road:
(4) After the front-axle wheels have been straightened,
switch the switching lever for the steering (4-8/3) to the
„rear-axle steering“ position.
(5) Release the parking brake (4-9/7).
