ahlmann AS 210 - Engine Flaps; Multi-Purpose Bucket

S220/S221/S230/S231/Z200 8-17
Maintenance 8
Figure 8-38
Figure 8-39
4x item 8-37/arrows Tip cylinder
8.2.18.8 Engine flaps
CAUTION
The hinges of the engine flaps (8-28/arrows) must
be lubricated every 50 operating hours.
8.2.18.9 Multi-purpose bucket
CAUTION
The bearing bolts of the multi-purpose bucket
must be lubricated every 10 operating hours.
NOTE
The bolt (8-39/arrow) must be lubricated on both
sides of the multi-purpose bucket.
Figure 8-37
i
