ahlmann AS 210 - Heater and Ventilation System; Set the Air Flow; Switching on the Heater

S220/S221/S230/S231/Z200 5-7
Operation 5
2
1
DANGER
If driving with the bucket arm swivelled is required
in special cases, the bucket/attachment must be
positioned close over the wheel and the travel
distance must be kept as short as possible. If
unevenness of the ground causes the support
system to lift a wheel off the ground, the bucket
arm must be briefly swivelled in the direction of
travel so that the axle block can be cancelled.
5.2.5 Heater and ventilation system
5.2.5.1 Set the air flow
(1) Turn the rotary switch (5-6/2) for the blower to position
0, 1, 2, or 3 depending on the air flow desired.
(2) Adjust the air flow direction with the nozzles at the
windshield (5-7/arrows) or in the floor area (5-8/arrows).
5.2.5.2 Switching on the heater
(1) Turn the knob (5-6/1) in the clockwise (cold) or the
anti-clockwise direction (warm) to reach the desired
temperature.
Figure 5-6
Figure 5-8
Figure 5-7
