S200/S201/Z200 12-3
Technical Data (Attachments) 12
12.1.1 Buckets
Bucket type Standard Lightweight Multi-purpose
bucket bucket bucket
Bucket volume m³ 2,1 2,4 1,8
Bucket width mm 2.700 2.700 2.700
Dead weight kg 730 760 840
Loads acc. to ISO 14397
Bulk density t/m³ 1,8 1,5 2,0
Dump load
- frontal kg 7.800 7.750 7.600
- swivelled kg 7.450 7.350 7.200
Payload
- frontal kg 3.900 3.875 3.800
- swivelled kg 3.725 3.675 3.600
A Total length mm 7.155 7.255 7.145
AA4 Max. dump angle ° 95 95
A2 Max. dump angle ° 45 45 45
B Max. dumping distance
at dumping angle 45° mm 2.190 2.270 2.360
G Dumping height at
max. dumping distance
and dumping angle 45° mm 1.350 1.290 1.285
H6 Depth of feed-in mm 90 90 90
H8 Dumping height at max. lifting height
and dumping angle 45° mm 3.420 3.360 3.355
H10 Max. working height mm 5.600 5.680 5.575
J Free lift height mm 3.660 3.660 3.660
LL Dumping distance at max. lifting height
and dumping angle 45° mm 890 970 985
L6 Dumping distance at max. lifting height
and dumping angle 45° mm 1.335 1.415 1.425
RR Max. dumping distance
at dumping angle 45° mm 1.740 1.820 1.910
Multipurpose bucket opened:
D Dumping distance at max. lifting height
and tilted bucket mm - - 1.170
HH13 Max. dumping height
with tilted bucket mm - - 4.120
MM Dumping distance at max. lifting height
and tilted bucket mm - - 720
