S200/S201/Z200 12-5
Technical Data (Attachments) 12
12.1.2 Fork-lift attachment
Tine length 1.600 mm
Tine height 70 mm
Dead weight 340 kg
Perm. payload N acc. to EN 474-3
frontal
- level ground (stability factor 1.25) 5.300 kg
- uneven ground (stability factor 1.67) 3.975 kg
swivelled
- level ground (stability factor 1.25) 4.500 kg
- uneven ground (stability factor 1.67) 3.375 kg
Perm. payload N (fork-lift attachment 300 mm above ground)
frontal
- level ground (stability factor 1.25) 6.400 kg
- uneven ground (stability factor 1.67) 4.800 kg
A Total length 7.950 mm
A5 Tilt angle 25°
B Min. reach 1.095 mm
C Max. reach 1.810 mm
D Reach at max. lifting height 950 mm
G Free lift height at max. reach 2.000 mm
H6 Depth of feed-in 100 mm
HH15 Free lift height at max. reach (upper tine edge) 4.100 mm
KK Max. reach 1.390 mm
LL Distance between tyre and payload 1.750 mm
MM Reach at max. lifting height 500 mm
PP Min. free lift height 750 mm
12.1.3 Lifting hook
Perm. payload acc. to DIN EN 474-3
Max. outreach (stability factor 2)
- frontal 2.350 kg
- swivelled 1.750 kg
Dead weight kg
A Total length 7.385 mm
DD Max. outreach 3.480 mm
HH Max. lifting height 5.425 mm
RR Max. outreach 3.030 mm
