S200/S201/Z200 12-7
Technical Data (Attachments) 12
12.1.4 Front-end excavator
Max. breakout force at the shovel cutting edge 6.200 daN
Max. tear-out force at the shovel cutting edge 3.100 daN
Shovel volume Shovel width Dead weight
acc. to DIN ISO 7451 acc. to DIN ISO 7451
0,129 m³ 300 mm 174 kg
0,193 m³ 450 mm 194 kg
0,257 m³ 600 mm 230 kg
0,343 m³ 800 mm 275 kg
D Max. digging depth over cutting edge acc. to DIN ISO 7135 2.650 mm
E Depth of feed-in 100 mm
H22 Max. dumping height acc. to DIN ISO 7135 3.900 mm
H24 Max. digging depth over cutting edge acc. to DIN ISO 7135 3.420 mm
H25 Depth of feed-in 1.420 mm
Working times at n
engine max.
:
- Stalk extension 0,8 s
- Stalk retraction 1,6 s
- Opening shovel 0,8 s
- Closing shovel 1,6 s
12.1.5 Grab bucket
Grab bucket type Grab bucket volume Scoop width Dead weight
0,245 m
3
600 mm 510 kg
C Max. dumping distance 4.065 mm
H6 Max. grab depth over cutting edge 3.270 mm
H7 Max. free lift height over shovel floor 4.100 mm
TT Max. grab depth over cutting edge 2.500 mm
NOTE
Only the grab buckets listed in the table above may be attached.
i
